| Typical material designation |
AISI 440A / UNS S44002 |
AISI 440B / UNS S44003 |
AISI 440C / UNS S44004 |
Confirm the designation, UNS number, product form, and applicable standard on the quotation and certificate. |
| Carbon, mass fraction |
0.60–0.75% |
0.75–0.95% |
0.95–1.20% |
Require heat-by-heat chemical analysis from an accredited laboratory or verified in-house laboratory. |
| Chromium, mass fraction |
16.00–18.00% |
16.00–18.00% |
16.00–18.00% |
Use positive material identification or laboratory spectroscopy to verify alloy identity. |
| Manganese and silicon |
Each normally ≤1.00% |
Each normally ≤1.00% |
Each normally ≤1.00% |
Check the complete chemistry against the selected standard rather than relying only on a grade name. |
| Phosphorus and sulfur |
Typically P ≤0.040%; S ≤0.030% |
Typically P ≤0.040%; S ≤0.030% |
Typically P ≤0.040%; S ≤0.030% |
Verify restricted elements and any customer-specific limits on the mill test certificate. |
| Heat-treatment capability |
Annealed, hardened, tempered, or stress-relieved conditions may be available. |
Annealed, hardened, tempered, or stress-relieved conditions may be available. |
Commonly selected where high hardened strength and wear resistance are required. |
Request furnace records, thermal-cycle parameters, hardness results, and lot traceability. |
| Relative corrosion performance |
Moderate; generally better in the annealed condition than after excessive hardening. |
Moderate; dependent on surface condition and heat treatment. |
Moderate; high carbon content can reduce corrosion resistance compared with lower-carbon stainless grades. |
Define the service environment and request corrosion testing when exposure conditions justify it. |
| Common product forms |
Sheet, plate, strip, bar, wire, and machined components |
Sheet, plate, strip, bar, wire, and machined components |
Sheet, plate, strip, bar, wire, and machined components |
Confirm dimensional tolerances, surface finish, straightness, edge condition, and minimum order quantity. |
| Applicable specification examples |
ASTM A276, ASTM A480, ASTM A959, or an agreed international equivalent |
ASTM A276, ASTM A480, ASTM A959, or an agreed international equivalent |
ASTM A276, ASTM A480, ASTM A959, or an agreed international equivalent |
The purchase order must identify the exact standard revision and acceptance criteria. |
| Quality management certification |
Not grade-specific |
Prefer a current ISO 9001 certificate covering the supplied process scope; verify certificate validity and issuing body. |
| Environmental and compliance documentation |
Depends on the end-use and customer requirements |
Request applicable environmental certificates, restricted-substance declarations, conflict-minerals statements, and regulatory documents. |
| Chemical composition test |
Required for grade confirmation |
Accept laboratory analysis, optical emission spectroscopy, or another validated method with instrument calibration records. |
| Mechanical testing |
Tensile strength, yield strength, elongation, and hardness as specified by product standard and condition |
Review test method, specimen orientation, sampling frequency, calibration status, and lot-level results. |
| Metallographic examination |
Recommended for critical or heat-treated parts |
Check carbide distribution, segregation, decarburization, inclusions, grain structure, and abnormal microstructural features. |
| Non-destructive testing |
Optional or contract-specific |
Specify ultrasonic, eddy-current, magnetic-particle, or liquid-penetrant testing where internal or surface discontinuities are critical. |
| Surface inspection |
Visual and dimensional inspection required |
Define acceptable scratches, pits, scale, edge cracks, weld repairs, roughness, and passivation condition. |
| Documentation package |
Material Test Certificate plus inspection records |
Require heat number, standard, dimensions, chemistry, mechanical results, heat treatment, inspection status, and authorized approval. |
| Traceability controls |
Heat-level traceability recommended |
Verify that the heat number remains linked from raw material receipt through processing, packing, and shipping documents. |
| Pre-shipment inspection |
Recommended for first orders and critical applications |
Use an agreed inspection plan covering quantity, dimensions, surface, packaging, marking, certificates, and sampling level. |
| Packaging and export readiness |
Moisture-resistant, corrosion-protective, and export-suitable packaging |
Confirm bundle protection, labels, heat numbers, net and gross weight, container suitability, and shipping documentation. |
